High Pressure Type Electromagnetic Flowmeter

Instrument and Meters >> Flowmeter Series >> High Pressure Type Electromagnetic Flowmeter

Product Description

High pressure electromagnetic flow sensor adopts special lining technology, which is resistant to high pressure and negative pressure. It is specially used in geology, petroleum exploration, and oil field systems to measure the volume flow of conductive liquids or liquid-solid two-phase media such as mud, cement slurry, and high-pressure water injection under high pressure conditions Measurement.

Technical Parameter
  • Nominal Diameter: DN25mm~DN250mm
  • Nominal Pressure: 6.3MPa,10MPa, 16MPa, 25MPa, 42MPa
  • Accuracy: ±0.5%,±0.3% or ±0.2%(optional
  • Lining Material: PTFE, F46, PFA
  • Electrode Material: SUS316,Hastelloy B, Hastelloy C, Titanium, Stainless Steel Coated Tungsten Carbide
  • Structure Type: Intgrate , split
  • Medium Temperature: –10°C ~ + 160°C
  • Ambient Temperature: -25°C ~ + 60°C
  • Dielectric Conductivity: ≥20us/cm
  • Explosion-proof Mark: Exd[ia, Ga]II CT6 Gb
  • Connection Method: Flange,oil type
